5.0 inch CTP | 5-point touch capacitive screen | GT911 controller | I2C interface capacitive touch screen | G+G UXTouch | 6 PIN plug-in FPC CTP

Bring an excellent touch experience to your 5.0-inch TFT series LCD screen! The size of this 5.0-inch CTP UXTouch cover Glass is customized for the user's product structure. The large cover, which is slightly larger than the 5.0-inch standard TFT size, makes the structure more compatible with the device. Users can also selectively print customized colors, patterns, and panels or perforated panels in various shapes on the surface. This touch screen and TFT display can choose optical bonding or frame-fit binding process.

The G+G (double glass) structure of this 5.0 inch CTP ensures durability and 85% high light transmittance, the picture is transparent and bright, and the overall power consumption is optimized. Equipped with GT911 chip, it achieves smooth 5-point touch response and the I2C interface is stable and reliable. In terms of connection, the FPC of this touch screen comes with a 6-pin connector. Users can easily assemble and disassemble the touch panel and TFT display. They can also choose FFCs of different lengths for connection according to the actual situation of the display and the main control board. The flexible design brings unlimited creativity.

We provide a full range of customized services: from interface definition, connection method (plug/weld/connector), process structure (G+G/G+FF/G+F/P+G/P+F), to cover form (size, 2.5D fillet, etc.), hardness level (3H/6H/7H/9H) and surface coating (AF /AG /AR), and even designated brand cover glass (such as Panda, Corning Gorilla), all can be realized on demand.

Perfect partner recommendation: standard screen TFT-H050A1SVIST6N40, or ready-to-use UART smart module HTM050A1-USART-ST V1.0. There is also a 1:1 cover option CTPH050A1_V0-1 that makes the touch screen and display perfectly fit in a 1:1 ratio. All series are RoHS certified and reliable in quality.
