TFT-H101A19HDINV5N40 | 10.1-inch TFT LCD Display with LVDS Interface | 800x1280 HD IPS Ultra-thin TFT Display

Introducing our premium 10.1-inch TFT LCD Display, engineered to deliver exceptional clarity and performance for demanding applications. This high-definition screen boasts an 800x1280 resolution with an IPS panel, ensuring vibrant colors and sharp details from every angle. Whether integrated into sophisticated instrumentation or cutting-edge portable electronic devices, this 10.1-inch TFT LCD Display provides a visual output that is both brilliant and reliable.

Durability meets ultra-thin design in this versatile module. With a slim profile and a compact outline, it is perfectly suited for space-constrained projects without compromising on a generous active viewing area. The robust 10.1-inch TFT LCD Display is built to last, featuring an anti-static ESD rating of 8KV and an operating temperature range of -20~70℃, guaranteeing stable performance in various environments.

At the heart of its connectivity is the LVDS interface, driven by the NV3051F chip, which ensures a stable, high-speed signal transmission and pristine image quality. A high brightness of 500 cd/m2 makes this display easily readable even under bright lighting conditions. For a powerful combination of HD visuals, ruggedness, and energy efficiency (3.3V power supply), choose this advanced 10.1-inch TFT LCD Display as the core of your next innovation.
